SPARK

Recessed adjustable rectangular downlight, luminaire body made of aluminium housing with white powder coated finish. Black finish and Honeycomb accessory available upon request.

Esem Mid 1.1

recessed downlight for indoor applications; recessed (ceiling, wall, shelf); Power consumption: max 3W (3 power LEDs x 1W); Power supply: max 350mA; Lumen output at source: 309 lm (3000K, 350mA); Delivered lumen output: 220 lm (3000K, 350mA, 22°); 3 power LEDs, 1/4 ANSI BIN, 50 000h L95 B10 (Ta 25°C); LED colour: 2700K, 3000K, 4000K, 5000K; Optics: 11° tiltable ±20°, 22° tiltable ±20°, 30° tiltable ±20°, 20°x45° tiltable ±20°; CRI Colour Rendering Index: 80

24 V, IP67 protected and IK10 certified, linear LED luminaire for indoor and outdoor in-ground installation. Suitable for installation into roads and parking lots according to EN 60598-2-13. To be walked on and traversed by vehicles with air filled tires (including trucks used for delivery). Polyurethane encapsulation offering a premium water proof sealing (values), UV resistance (no coloration or increase of absorption) chemical stability against urban gazes and protection against abrasion. Stainless Steel V4A housing delivered with male/female IP67 connectors. Available either with an opal top layer or transluscent with an internal 10° and 30° lenses for wall grazing. Light source assembled using state of the art automated Reel-to-Reel (R2R) production process supporting LED Linear™ Tj Away thin flexible circuit board technology.

Luminaire made of aluminium alloy, aluminium and stainless steel BEGA Unidure® coating technology Colour graphite Safety glass with optical structure Silicone gasket Luminaire with mounting base made of hot-dip galvanised steel according to EN ISO 1461 for bolting on a foundation or anchorage unit Base plate with 2 elongated holes Width 9 mm · 220 mm spacing Connection box 71 084 for through-wiring – for 2 cables up to 7 × 6
