LINEALIGHT

CEILING LIGHT
INDOOR LIGHTING
82006W15

Single emission ceiling lights for indoor application. The warm white LED light source is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating. The ingress protection degree is IP40; the total weight is of 0.6 kg. The device features protection class II and can be ceiling-mounted. Compliant with the EN 60598-1 standard and its specific provisions.

Specification

Power
19.5W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
1677LM
Finishing
BLACK
IP Rating
IP40
Color Rendering
CRI 92
Driver
ON/OFF DRIVER

See more

LUCE & LIGHT
SPOTLIGHT
OUTDOOR LIGHTING

Pivot 2.0,projector for outdoor applications surface mounted (ceiling, wall, ground, spike), surface mounted (ceiling, wall, floor)Power consumption: 10W, 14WPower supply: 24Vdc

Lumen output at source: 1173 lm (3000K, 14W, CRI >90), 1397 lm (3000K, 14W, CRI 80), 821 lm (3000K, 10W, CRI >90), 978 lm (3000K, 10W, CRI 80)

Delivered lumen output: 1064 lm (3000K, 25°, 14W, CRI 80), 676 lm (3000K, 25°, 10W, CRI >90), 835 lm (3000K, 25°, 10W, CRI 80), 862 lm (3000K, 25°, 14W, CRI >90),1 COB LED, 3-st

LINEALIGHT
CEILING LIGHT
INDOOR LIGHTING
Single emission ceiling lights for indoor application. The warm white LED light source with a extra wide flood light distribution is composed of 1 powerled LEDs. The device body is made of ot58 brass and features a embossed white ral 9003 finish, processed by means of powder coating. The ingress protection degree is IP52; the total weight is of 0.116 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.12 m length. The device features protection class III and can be ceiling-mounted. Compliant with the EN 60598-1 standard and its specific provisions.
LUCI
LINEAR LIGHT
INDOOR LIGHTING
Redesigning our dot-free rigid light series by slimming the thickness.'Homogeneous linear light with a height of 5.8mm only. Highly versatile and blends in various applications.60 different length variations from 33mm up to 1508mm.
TARGETTI
RECESSED DOWNLIGHT
INDOOR LIGHTING

Turned aluminium body and integrated heat sink with painted flange. Painted, turned, removable front ring, the LED source are set back 40mm into the fixture to limit glare. Passive cooling system.
