SPARK

RECESSED MAGNETIC TRACK LINEAR
INDOOR LIGHTING
SPK6104R-30W
Recessed or Surface mount magnetic track system containing linear light, spot light, wall washer and pendant light module to create your imagination of illumination purposes in a wonderful visual experience. Low voltage DC48V plus double insurance installation system magnetic + click make it work safely.

Specification

Power
30W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
840LM
Finishing
BLACK
IP Rating
IP20
Color Rendering
CRI90
Driver
ON/OFF DRIVER

See more

LINEALIGHT
RECESSED DOWNLIGHT
INDOOR LIGHTING
Single emission downlights for indoor application. The warm white LED light source with a flood light distribution is composed of 1 powerled LEDs. The device body is made of aluminium 6026 and features a embossed black ral 9005 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.128 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.170 m lenght. The device features protection class III and can be ceiling-mounted, with a 35 mm diameter hole (in plasterboard) with an outer casing, code 99848 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.
SPARK
RECESSED DOWNLIGHT
INDOOR LIGHTING

Recessed fixed downlight made of aluminium housing with white powder coated finish. Inner reflector available in Silver, Chrome black, Mirror chrome and white color finish. Cut-out Ø130mm.

FLOS
ADJUSTABLE DOWNLIGHT
INDOOR LIGHTING
Eclectic Ø90 Dim To Warm.Adjustable Downlight (40º tilt,360º rotation). “Flat” style façade.Necessary installation pre-frames,not included (to be orderedseparately). Recessed position ofthe LED: 49º cut-off angle. IP20water tightness (for IP54, pleaseask the dedicated accessory).Alternative options for lenses,orientation modules and stylefaçades are available as spare parts. The ingress protection degree is IP20.
IGUZZINI
LINEAR GRAZER
OUTDOOR LIGHTING

Direct light luminaire, designed to use monochrome LED lamps, DALI 48Vdc dimmable with searching and addressing function. Ceiling-, wall- or surface-mounted. Consists of a body and supports for installation, to be ordered separately. The body is made of extruded aluminium and includes die-cast aluminium end caps with 50/60 Shore A silicone seals. It is subjected to a multi-step, pretreatment process, in which the main phases are degreasing, fluorozirconation (a protective surface film) and sealing (with a nanostructured silane layer). The following painting stage consists of a primer and a liquid acrylic paint, cured at 150°C, with a high level of weather and UV ray resistance. The top of the optical assembly is closed by a 3 mm thick transparent glass screen, fixed with silicone.
