LINEALIGHT

SURFACE TRACKLIGHT

INDOOR LIGHTING

81632W60

Single emission projectors for indoor application.The warm white LED light source with a wide flood light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating. The ingress protection degree is IP20; the total weight is of 0.612 kg. The device features protection class II and can be ceiling-mounted. Compliant with the EN 60598-1 standard and its specific provisions.

Specification

Power

29W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

2138LM

Finishing

BLACK

IP Rating

IP20

Color Rendering

CRI 92

Driver

ON/OFF DRIVER

SPARK

RECESSED MAGNETIC TRACK PENDANT

INDOOR LIGHTING

Recessed or Surface mount magnetic track system containing linear light, spot light, wall washer and pendant light module to create your imagination of illumination purposes in a wonderful visual experience. Low voltage DC48V plus double insurance installation system magnetic + click make it work safely. Reflector come with Silver, Chrome Black and White and honeycomb accessory available upon request.

IGUZZINI

ADJUSTABLE DOWNLIGHT

INDOOR LIGHTING

Round recessed luminaire with contact frame. Adjustable version that rotates internally by 355° and tilts by a maximum of 30°. The swivel unit rotates in a set back position in relation to the surface of the ceiling in order to guarantee precise, comfortable light diffusion and reduce direct glare significantly. IP20.

HELVAR

CONTROL SYSTEM

The Relay Contact Module is an ultra compact DINrail mounted unit with connections for four relay outputs and an M-BUS network. Each feed through relay can switch 5A with a maximum module load of20A.Each of the four relays are individually addressable and are all synchronised to zero crossing of the ACsine wave referenced to the module mains supply. This minimises the potential arc damage that can occur to the contacts.
