LINEALIGHT

Housing of corrosion‑resistant die‑cast aluminum AlSi12, double polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass flush with frame, anti‑reflective coating from 1 side, dark screenprint, for loads up to max. 5000 kg (according to IEC / EN 60598‑2‑13), silicon gasket, cover frame and closure with 6 stainless steel screws, cable gland: M20, connecting terminal: 3 pole, highly efficient faceted rotationally symmetrical reflector, lockable, tilt range: 0‑15°, lockable, 0,8 m cable H07RN‑F3G1, integral driver (AC/DC), CRI > 80, max 3 SDCM, service life L90/B10 > 50.000 h, Beam angle (fwhm): 31°, luminous flux: 849 lm, wattage: 11 W, delivered lumens 77 lm/W, protection type IP68, protection class I, impact resistance IK10, dimensions: Ø 180 mm, width 152 mm, weight 2.6 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE and ENEC marks.

The new Cyclones are our best-ever outdoor enclosures, offering unparalleled protection for large format video projectors between 20-45k lumens, in any climate type. Cyclone enclosures are projector-specific and may be produced for you for any projector in Landscape, Portrait and Ultra Short Throw formats. Each Cyclone model has been thoroughly tested and approved with its designated projector before being released for production. Featuring lightweight aluminum welded construction, Cyclone is an ideal choice for any outdoor projection project. Its powerful AC fan provides efficient cooling, while its salt fog filtering and positive pressure option provides ultimate projector protection.

All Cyclones come with four M12 threaded sockets — one at each corner — top and bottom. Larger models have additional threaded sockets midway along their length for additional security. Stainless steel bolts are provided for attachment to any suitable support structure.
