Product Detail | Bloxlimited

LINEALIGHT

RECESSED DOWNLIGHT

INDOOR LIGHTING

81122W15

Single emission downlights for indoor application. The warm white LED light source with a spot light distribution is composed of 1 powerled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a white finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.277 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.170 m length. The device features protection class III and can be ceiling-mounted, with a 70 mm diameter hole (in plasterboard) with an outer casing, code 83064 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.

Specification

Power

Color Temperature

3000K

Light Source Type

LED

Lumen Output

307LM

Finishing

WHITE

IP Rating

IP44

Color Rendering

CRI 92

Driver

ON/OFF DRIVER

WIBRE

UNDERWATER LIGHT

OUTDOOR LIGHTING

With 18 linearly arranged highperformance LEDs, the robust stainless steel recessed spotlight with its above-average high quality creates a wide light distribution that homogeneously illuminates the entire surface of the water in large public swimming pools or hotel pools. It is also used for marking lines in sports pools. Options ranging from cool to neutral to warm white, blue and RGB are available as colour temperatures. Thanks to the swivelling capability of the LED unit during production, the light cone can be directed onto the floor to achieve better illumination and minimise glare.

PHOS

RECESSED DOWNLIGHT

OUTDOOR LIGHTING

The Nano Eyeconic Mini Trim Fixed is an incredibly discreet recessed, directional downlight with a Ø38mm bezel and features a beautifully sculpted anti-glare baffle. Unique, elegant small aperture. Easily interchangeable optics. Flawless finishes available on all components.

PROLICHT

ADJUSTABLE DOWNLIGHT

INDOOR LIGHTING

The recessed spot MECHANIQ SQUARE EFFICIENCY DOUBLE from the familiy MECHANIQ consists of aluminum-die-cast. With 3 powder coated options 15625 colour combinations can be achieved. Stated photometric values correspond to operation by 500 mA; a suitable ballast needs to be sourced separately and is not scope of delivery. Dimming (# 220-0256) depends on the used ballast and may vary. The spot with direct illumination corresponds to protection class SK3 at IP20. Multiple applications possible due to comprehensive adjustment options. Rotability is 355° and additionally MECHANIQ SQUARE EFFICIENCY DOUBLE is tiltable by 45°. A PROLICHT lense pack is optionally available.
