Performance floodlight with G½ mounting bush in compact design. The floodlight can be bolted together with any female thread G½ according to ISO 228 supplied by others or to BEGA accessories. Symmetrical wide beam light distribution Half beam angle 46° For special lighting applications, the symmetrical light cone can be changed to a flat beam using an additional diffuser lens. Luminaire made of aluminium alloy, aluminium and stainless steel BEGA Unidure® coating tehnology Clear safety glass Silicone gasket Reflector surface made of pure aluminium Optical silicone lens · BEGA Hybrid Optics® Rotation range of floodlight 350° Swivel range - 30°/+140° Mounting bracket with G½ threaded connection Thread length: 10mm Connecting cable X05BQ-F 5G1mm² Cable length 1m BEGA Ultimate Driver. IP65,IK08.

Surface mount track spotlight made of die cast aluminium housing and come with different diameter such as Ø55, Ø65, Ø70 and Ø75mm. Wattage from low 6W to 35W max. Fixture finishing available in Black or White color. Wide bean angles are avaiable. IP20.

FUSION Linear profile with two Accent Light (AL300) inserts, one General Light (GL600) insert and ON-OFF driver as surface mounted; white profile channel (RAL 9016) and black reflector; LED 37W; measurement 1200mm x 50mm; CCT 3000K with an LED Output of 4000lm; high colour rendering at an index of CRI90; after a lifetime of 50000h min. 80% of the luminous flux with energy efficient OSRAM LED Chips; 5 years warranty; lighting perfectly suitable for reading, writing as well as computer and control work according to DIN EN 12464-1 (UGR<19); degree of housing protection according to DIN EN 60529 (IP20)

24 V, IP67 protected and IK10 certified, linear LED luminaire for indoor and outdoor in-ground installation. Suitable for installation into roads and parking lots according to EN 60598-2-13. To be walked on and traversed by vehicles with air filled tires (including trucks used for delivery). Polyurethane encapsulation offering a premium water proof sealing (values), UV resistance (no coloration or increase of absorption) chemical stability against urban gazes and protection against abrasion. Stainless Steel V4A housing delivered with male/female IP67 connectors. Available either with an opal top layer or transluscent with an internal 10° and 30° lenses for wall grazing. Light source assembled using state of the art automated Reel-to-Reel (R2R) production process supporting LED Linear™ Tj Away thin flexible circuit board technology.
