Products
LINEALIGHT
RECESSED DOWNLIGHT
INDOOR LIGHTING
80110W30
Single emission downlights for indoor application. The warm white LED light source with a flood light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating. The ingress protection degree is IP40; the total weight is of 0.150 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.15 m length. The device features protection class III and can be ceiling-mounted, with a 60 mm diameter hole (in plasterboard) with an outer casing, code 89374 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.
Specification
- Power
- 7W
- Color Temperature
- 3000K
- Light Source Type
- LED
- Lumen Output
- 689LM
- Finishing
- BLACK
- IP Rating
- IP40
- Color Rendering
- CRI 80
- Driver
- ON/OFF DRIVER
