93355W30
Single emission downlights for indoor application. The warm white LED light source with a flood light distribution is composed of 1 arrayled LEDs. The device body is made of uv resistant polycarbonate and features a embossed black ral 9005 finish, processed by means of liquid painting; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.2 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.15 m length. The device features protection class III and can be ceiling-mounted, with a 65 x 65 mm hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.

Specification

Power
7W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
636LM
Finishing
BLACK
IP Rating
IP44
Color Rendering
CRI 80
Driver
ON/OFF DRIVER

See more

ILIGHT
CONTROL SYSTEM
CONTROL SYSTEM

The SCMR1220 is a key building block when specifying high power switching control. This 12 channel, feed through-latching relay controller enables lighting loads up to 20A to be switched. The twelve TV8 rated relays support resistive, capacitive, and inductive lighting loads, as well as non-lighting loads of any voltage up to 230VAC. The economical design of SCMR1220 provides a high density of channels in a small footprint, minimising the required space and cost of installation.

LIGHTFORMS
SURFACE MOUNTED LIGHT
INDOOR LIGHTING
Draco is the tallest member of our cylinder lighting family. Its strong long form utilises LEDil reflectors and Osram chips (with 1 and 2 Macadam's Ellipses colour consistency). Draco is available is in a full range colour temperatures and with integral control gear as standard.
LINEALIGHT
NIGHT LIGHT
OUTDOOR LIGHTING
Single emission wall lights for indoor application. The super warm LED light source with a asymmetric wallwasher light distribution is composed of 1 powerled LEDs with CCT of 2700 K and a CRI 80; the source luminous flux is 145 lm, with a 145.0 lm/W nominal luminous efficacy. The device body and features a embossed white ral 9003 finish, processed by means of open pore anodizing + powder coating; the diffuser is made of silicone resin. The ingress protection degree is IP65, IK 10.
LIGHTFORMS
SUSPENDED PENDANT LIGHT
INDOOR LIGHTING
MoonRing 1 sweeps through and around interior spaces with peaceful, harmonic halos of light. Available in suspended and surface mount models, the luminaire achieves its mystical, soft gleam from a low wattage decorative LED source weaved within a narrow housing. Choose from several different diameter rings comprised of four joining segment arcs. Or, creatively join segment arcs together to form half-circles, S-shapes, ovals and other curved configurations. MoonRing can also be joined with straight sections of Lightplane 1 S.
