BEGA

Floor or ground-recessed luminaire designed to use white monochrome LED lamps, a fixed optic and powered with a continuous, current of 350/500/700mA. The product consists of a flush-mounted glass cover and an optical assembly made of AISI 304 stainless steel. The extra-clear sodium-calcium glass cover, with black serigraphy, is fixed to the optical assembly by means of a silicone seal.

XOOLUX™ NANO is a minimalistic and flat luminaire designed primarily for grazing applications. The updated IP classification now stretch to IP67, meaning water resistance and suitable for outdoor use. Detailed specification text in download section. DIMENSIONS & AVAILABLE LENGTHS 41.4 mm x 17.7 mm 4 Standard lengths (L): 271.4 mm / 521.4 mm / 771.4 mm / 1,021.4 mm. The ingress protection degree is IP67.

Inground luminaire made of die-cast aluminium alloy with very low copper content. A4 Stainless steel screws. The product is painted follow a continuous two step paint process (epoxy-based primer + polyester-based color finish), which allows to generate a single thick protective coating which then generates protective barrier against atmospheric agents and UV rays. IP68 protection with Full Dry system which avoids condensation inside the product. IK10

Housing made of corrosion‑resistant die‑cast aluminum AlSi12, polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass, anti‑reflective coating from 1 side, silicon gasket, closure with 2 stainless steel screws, mounting bracket: 1 elongated hole Ø 7 mm, spacing 18 mm, 1 centre hole Ø 8.5 mm, tilt range: 180°, cable gland: M16, connecting terminal: 3 pole, precise PMMA optics, integral driver (AC/DC), CRI > 70, max 2 SDCM, service life L90/B10 > 50.000 h, luminous flux: 679 lm, wattage: 9 W, delivered lumens 75 lm/W, protection type IP67, protection class I, impact resistance IK08, windage area 0,012 m², dimensions: Ø 123 mm, width 87 mm, weight 1.8 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE and ENEC marks. Customized solutions and modifications are possible: Special ral, db or ncs colours as polyester powder coat, luminaires in 2700 K and other colour temperatures and versions for high ambient temperature.
