Preview Real Lighting Products in Blox 3D Simulator Using IES Files
Products
LINEALIGHT
WALL LIGHT
INDOOR LIGHTING
93522W00
Single emission wall lights for indoor application. The warm white LED light source with a diffused light distribution is composed of 1 powerled LEDs. The device body is made of aluminium 6026 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of uv resistant polycarbonate with a liquid painting treatment. The ingress protection degree is IP44; the total weight is of 0.120 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.170 m length. The device features protection class III and can be wall lights or ceilingmounted, with a 23 mm diameter hole (in plasterboard) with an outer casing, code 98992 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.
Specification
- Power
- 1W
- Color Temperature
- 3000K
- Light Source Type
- LED
- Lumen Output
- 57LM
- Finishing
- ANODISED ALUMINUM
- IP Rating
- IP44
- Color Rendering
- CRI 80
- Driver
- ON/OFF DRIVER
See more
