81688W50
Single emission lines for outdoor application. The warm white LED light source with a medium wide flood light distribution is composed of 18 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68; the total weight is of 1.535 kg. The power supply cable is included and features a 0.250 m length. The device features protection class II and can be floor-mounted with an outer casing, code 99763 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.

Specification

Power
14.4W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
1255LM
Finishing
ANODISED ALUMINUM
IP Rating
IP68
Color Rendering
CRI 80
Driver
ON/OFF DRIVER

See more

FORMALIGHTING
SURFACE MOUNTED DOWNLIGHT
INDOOR LIGHTING

Ceiling and wall mounted spotlight with light body and driver canopy in cast aluminium. Inclusive of reflector in metalized PC. Light body is designed for passive cooling. Available in 3 different sizes. Tiltable vertically 0-90° and rotatable horizontally 360°.

IGUZZINI
SURFACE LINEAR LIGHT
OUTDOOR LIGHTING
Direct light luminaire, designed to use monochrome LED lamps, DALI dimmable with searching and addressing function. Ceiling, wall or surface-mounted. It consists of a body and installation brackets to be ordered separately. The body is made of extruded aluminium and includes die-cast aluminium end caps with 50/60 Shore A silicone sealsIP66,IK06.
RCL
ADJUSTABLE DOWNLIGHT
INDOOR LIGHTING

DRX5 is a compact recessed luminaire that masters the art of pin spotting and accent lighting while combining excellent beam quality with all the benefits of RCL technology. The DRX5 is available with three fixed CCT light engines, delivering up to 1,474 lumens from a wide selection of fixed beam options as well as zoom powered by Lensvector. DRX5 is also available with Tunable White and RGBW - visit their specsheets to learn more.

LINEALIGHT
SURFACE MOUNTED DOWNLIGHT
OUTDOOR LIGHTING

Surface mount downlights for indoor application come with a medium flood light distribution is composed of 1 power led. Luminaire body is made of ot58 brass and features a white finish, processed by means of powder coating. The ingress protection degree is IP52;
