81688W08
Single emission lines for outdoor application. The warm white LED light source with a flood light distribution is composed of 18 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68; the total weight is of 1.535 kg. The power supply cable is included and features a 0.250 m length. The device features protection class II and can be floor-mounted with an outer casing, code 99763 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.

Specification

Power
14.4W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
1553LM
Finishing
ANODISED ALUMINUM
IP Rating
IP68
Color Rendering
CRI 80
Driver
ON/OFF DRIVER

See more

IGUZZINI
RECESSED DOWNLIGHT
INDOOR LIGHTING

This flush mount luminaire suits false ceilings 1–25 mm thick, secured with steel springs. It features a painted die-cast aluminum body and a scratch-resistant, metallic-finish reflector for high efficiency and visual comfort. Frame versions offer UGR < 19, IP54 on the visible part, and various wiring options: On-Off, DALI, or emergency inverter. Installation space requirements are detailed in the instruction sheet.

FORMALIGHTING
RECESSED DOWNLIGHT
INDOOR LIGHTING
Round or Square mounting trim in cast aluminium with spring for installation mounting on a ceiling thickness of 1-25mm. Luminaire body in cast alluminum. Easy relamping tool-free via removable lamp front ring. Available in two different sizes. Adjustable version tiltable vertically 0-40° and rotatable horizontally 350°.
IGUZZINI
RECESSED DOWNLIGHT
INDOOR LIGHTING

Round fixed luminaire designed to use LED lamps with C.o.B. technology. Version with rim for surface-mounting. Prismatic thermoplastic reflector complete with flux enhancer and anti-glare screen located at the centre of the optic. The anti-glare screen is made of thermoplastic vacuum-metallised with aluminium vapours finished with a protective anti-scratch layer. Dissipater made of painted grey die-cast aluminium. Product complete with LED lamp in warm white colour tone (3500K). Light emission U

IGUZZINI
RECESSED DOWNLIGHT
INDOOR LIGHTING

Round recessed luminaire with contact frame. Fixed Super Comfort version: the LEDs are set a long way back to minimize glare and guarantee a high level of visual comfort. The main body is made of die-cast aluminium with a radiant surface that guarantees optimum heat dissipation. Metallised, thermoplastic, high definition reflector - medium optic. Structure with die-cast aluminium external contact frame with a single white finish.
