IGUZZINI

RECESSED LINEAR LIGHT
OUTDOOR LIGHTING
LINEALUCE_UB44

Direct light luminaire, designed to use monochrome LED lamps, DALI 220÷240Vac dimmable with searching and addressing function and transparent glass cover. Ground-, wall- and ceilingrecessed. Option of installation in continuous lines of up to a max length of 10.5m only for ground-recessed installation. Made up of a body, end caps, an outer casing and caps to be ordered separately. Extruded aluminium body, with die-cast aluminium end caps complete with silicone seals.

Specification

Power
34.3W/M
Color Temperature
2700K
Light Source Type
LED
Lumen Output
2278LM/M
Finishing
GREY
IP Rating
IP67
Color Rendering
CRI 90
Driver
ON/OFF DRIVER

See more

LED LINEAR
SURFACE LINEAR LIGHT
OUTDOOR LIGHTING

Luminaire with 45° adjustable head with a clear encapsulation and reflectors for general lighting applications. Polyurethane is utilized in XOOLUM to make it more resistant to impact from salt water UV-light and solvents. Modular mounting and lighting scenery thanks to its LEDs-Click technology enabling a 45° tilt of the luminaire head. Appealing form factor of 25.4mm*31mm which blends easily in any architectural concepts.

XAL
WALLWASHER
INDOOR LIGHTING

Round recessed spotlight luminaire is made of die-cast aluminium housing. 1 lamp; surface chrome. 360° rotatable; installation without tools in mounting set due to patented ball catch system. Round installation housing. Suitable for ceiling thickness of 2-25 mm. Passive cooling of the LEDs through improved heat sink geometry, no multiple shadows. DIMENSION: (D080x(H)48mm.

LINEALIGHT
WALLWASHER
OUTDOOR LIGHTING
Single emission lines for outdoor application. The warm white LED light source is composed of 18 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP67; the total weight is of 4.8 kg. The power supply cable is include and features a 0.2 m length. The device features protection class I and can be wall lights or floormounted with an outer casing, code 98673(for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.
LINEALIGHT
SPOTLIGHT
INDOOR LIGHTING

Single emission projectors for indoor application. The warm white LED light source with a spot light distribution is composed of 1 arrayled LEDs with CCT of 3000 K and a CRI 98; the source luminous flux is 3978 lm, with a 165.8 lm/W nominal luminous efficacy.
