IGUZZINI

SURFACE LINEAR LIGHT

OUTDOOR LIGHTING

LINEALUCE_BK41

Direct light luminaire, designed to use monochrome LED lamps. Ceiling- and wall-mounted. Consists of a body and supports for installation (to be ordered separately). Extruded aluminium body, with zamak die-cast end caps complete with silicone gaskets. Coated with liquid acrylic paint with a high level of weather and UV ray resistance. IP66,IK05.

Specification

Power

12.4W/M

Color Temperature

3000K

Light Source Type

LED

Lumen Output

1278LM/M

Finishing

GREY

IP Rating

IP66

Color Rendering

CRI>80

Driver

ON/OFF DRIVER

IGUZZINI

WALL LIGHT

OUTDOOR LIGHTING

Outdoor wall-mounted luminaire come with wide flood optic. The luminaire consists of an optical assembly upper cap and base for fixing to the wall. The optical assembly upper cap and base are made of die-cast aluminium alloy coated with liquid acrylic paint in high level of resistance to weather and UV rays. Transparent tempered sodium, calcium safety glass with customised grey serigraphy 4 mm thick joined to the optical assembly with silicone. The adjustable fixing bracket is made of painted aluminium. It has a single stainless steel M14x1 cable gland and FEP outlet cables L=150mm, electronic circuit with warm white LED and highly reflective thermoplastic internal reflector. IP66, IK07
