LINEALIGHT

WALLWASHER

OUTDOOR LIGHTING

82331W08

Single emission lines for outdoor application. The warm white LED light source is composed of 12 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68; the total weight is of 1.020 kg. The power supply cable is included and features a 0.250 m length. The device features protection class II and can be floor-mounted with an outer casing, code 99913 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.

Specification

Power

16.5W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

878LM

Finishing

ANODISED ALUMINUM

IP Rating

IP68

Color Rendering

CRI 80

Driver

ON/OFF DRIVER

FORMALIGHTING

SURFACE LINEAR LIGHT

OUTDOOR LIGHTING

Surface mounted modular system in die cast aluminium. Available in different length configurations based on a 83mm link (2 LED per link) with a 76mm increment. Section 34x36.6mm. Its flexible structure maintain a constant 38mm pitch between the LED. Its flexible design ensures a consistent 38mm pitch between LEDs for seamless light distribution. The system is supplied inclusive of driver for easy integration and installation.

LIGHTFORMS

SURFACE MOUNTED LIGHT

OUTDOOR LIGHTING

MoonFull is a round luminaire with a diffuse acrylic, direct-side lens available in multiple diameters with either direct, indirect or direct/ indirect distribution. May be installed as a suspended pendant or surface mounted.

FLOS

ADJUSTABLE DOWNLIGHT

INDOOR LIGHTING

Recessed luminaire with LED light source. Remote transformer not included. Installation frame not necessary. Diffusing lens included. The ingress protection is IP20 and IP54.

PENGKE LIGHT

ADJUSTABLE DOWNLIGHT

INDOOR LIGHTING

The XQ-10030 Series is a recessed double downlight with twin 20W CREE LEDs, delivering up to 2499 lumens with CRI ≥90. Its pill-shaped form and beam options (15°/24°/38°) provide precise, clean illumination ideal for retail or healthcare spaces. Available in multiple finishes, IP44 rated.
