LINEALIGHT

Surface mounted, pendant luminaires, available in cubic and cylindrical shaped. Though different in shape, still uniform in look, as both shapes have a deeper recessed LED module with a conical, coloured insert in front. While the deeper recessed LED module reduces the glare, the choice in colour creates possibilities for playful and attractive lighting solutions. Alongside the different shapes, this family offers indoor and outdoor luminaires, a perfect solution when recessing is not an option. Furthermore, the WDL versions of Boxy are standalone luminaires for an easy wireless CTRL Delta lighting set-up.

IP66. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compres sion Gasket. Luminaire is factory-sealed and does not need to be opened during installation.Remote 24VDC power supply to be ordered separately. Optical accessories are factory-installed.To be specified at time of ordering.

Single emission downlights for indoor application. The warm white LED light source with a medium flood light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.860 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.300 m length. The device features protection class III and can be ceiling-mounted, with a 127 mm diameter hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.

Single emission lines for indoor application. The warm white LED light source with a general lighting light distribution is composed of 54 topled LEDs with CCT of 3000 K and a CRI 80 the source luminous flux is 2020 lm, with a 134.7 lmW nominal luminous efficacy. The device body is made of aluminium and features a aluminium finish, processed by means of anodisation the diffuser is made of PC. The ingress protection degree is IP40 the total weight is of 2.15 kg. The power supply driver is included in the delivery. The total absorbed power is 15 W. The device features protection class I and can be wall lights or ceilingmounted, with a 43 x 1005 mm hole in plasterboard.
