LIGHTFORMS

Housing made of corrosion‑resistant die‑cast aluminum AlSi12, polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass, anti‑reflective coating from 1 side, dark screenprint, silicon gasket, closure with 4 stainless steel screws, mounting bracket: 1 elongated hole Ø 7 mm, spacing 18 mm, 1 centre hole Ø 8.5 mm, tilt range: 180°, cable gland: M20, connecting terminal: 3 pole, precise PMMA optics, integral driver (AC/DC), CRI > 80, max 2 SDCM, service life L90/B10 > 50.000 h, Beam angle (fwhm): 25°, luminous flux: 549 lm, wattage: 7 W, delivered lumens 78 lm/W, protection type IP65, protection class I, impact resistance IK08, windage area 0,008 m², dimensions (L×H×W): 85 × 86 × 85 mm, weight 0.9 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE mark. Customized solutions and modifications are possible: Special ral, db or ncs colours as polyester powder coat, luminaires in 2700 K and other colour temperatures and versions for high ambient temperature.

Recessed walkover inground light, body made of aluminium alloy, Trim in AISI 316L stainless steel, made with a CNC lathe. Finishes brass, stainless steel.10-mm-thick transparent extra-clear glass, high transmittance to ensure chromatic uniformity of light and tempered for excellent resistance to knocks and scratches.

Outdoor floodlight housing made of corrosion?resistant die?cast aluminum AlSi12, polyester powder coated by high?quality and UV?stabilized coating process. All exterior parts are stainless steel, tempered safety glass, anti?reflective coating from 1 side, dark screenprint, silicon gasket, closure with 4 stainless steel screws. Protection type IP65, protection class I, impact resistance IK08. DIMENSION : (L×H×W): 152 × 120 × 152 mm

V-FLEX series bendable / twistable LED Strip for ceiling cove, come with 200mm, 600mm, 1000mm and 3000mm length. Available in Mono CCT and Tunable CCT version. Rigid flexible dark spot-less design by the use of double-mould / overmould polymer at the both ends of profile casing. Minimized voltage drop by the use of cable running through the profile. DIMENSION : L1000*W19*H12MM
