LIGHTFORMS

RECESSED LINEAR LIGHT

INDOOR LIGHTING

LF156957

Slimline 1.25 is a compact and streamlined luminaire with a 33mm, extruded aluminum channel that provides direct only or indirect/direct illumination. The fixture can be configured with linear lamping, spots or combinations of the two. Integral driver. High-impact acrylic lens. Individual or continuous row mounting. Available in suspended, wall or surface-mount models.

Specification

Power

37.2W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

2038LM

Finishing

BLACK

IP Rating

IP20

Color Rendering

CRI 90

Driver

ON/OFF DRIVER

SPARK

SURFACE MOUNTED DOWNLIGHT

INDOOR LIGHTING

Surface mounted cyclinder downlight

LINEALIGHT

WALLWASHER

OUTDOOR LIGHTING

Single emission lines for outdoor application. The warm white LED light source with a elliptical light distribution is composed of 22 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP67; the total weight is of 2 kg. The power supply cable is included and features a 0.2 m length. The device features protection class I and can be wall lights-mounted. Compliant with the EN 60598-1 standard and its specific provisions.

LED LINEAR

LED NEON TUBE

OUTDOOR LIGHTING

IP67 flexible 24 V linear LED strip up to 7.5 m in length. Polyurethane encapsulation offering a premium water proof sealing, UV resistance, chemical stability against urban gazes and protection against abrasion. White lower casing for higher efficiency (better light extraction). Delivered with 200 mm IP67 mini connectors on both ends. Constant Voltage LED strip with 62.5 mm and a small LED pitch of 8.93 mm the first choice for outdoor applications with a direct top view or indirect lighting with low construction depths – with perfectly homogeneous light. Assembled using state of the art automated Reel to Reel (R2R) production process supporting LED Linear™ Tj Away thin flexible circuit board technology.
