LED LINEAR

INGROUND LINEAR LIGHT

OUTDOOR LIGHTING

VARIOLED OCEANOS HYD HD10 W930/1020-30D IP67

24 V, IP67 protected and IK10 certified, linear LED luminaire for indoor and outdoor in-ground installation. Suitable for installation into roads and parking lots according to EN 60598-2-13. To be walked on and traversed by vehicles with air filled tires (including trucks used for delivery). Polyurethane encapsulation offering a premium water proof sealing (values), UV resistance (no coloration or increase of absorption) chemical stability against urban gazes and protection against abrasion. Stainless Steel V4A housing delivered with male/female IP67 connectors. Available either with an opal top layer or transluscent with an internal 10° and 30° lenses for wall grazing. Light source assembled using state of the art automated Reel-to-Reel (R2R) production process supporting LED Linear™ Tj Away thin flexible circuit board technology.

Specification

Power

10W/M

Color Temperature

2800K

Light Source Type

LED

Lumen Output

700LM/M

Finishing

WHITE

IP Rating

IP67

Color Rendering

CRI95

Driver

ON/OFF DRIVER
