VARIOLED OCEANOS IQW HYDRA HD12/1020-OP IP67

24 V, IP67 protected and IK10 certified, linear LED luminaire for indoor and outdoor in-ground installation. Suitable for installation into roads and parking lots according to EN 60598-2-13. To be walked on and traversed by vehicles with air filled tires (including trucks used for delivery). Polyurethane encapsulation offering a premium water proof sealing (values), UV resistance (no coloration or increase of absorption) chemical stability against urban gazes and protection against abrasion. Stainless Steel V4A housing delivered with male/female IP67 connectors. Available either with an opal top layer or transluscent with an internal 10° and 30° lenses for wall grazing. Light source assembled using state of the art automated Reel-to-Reel (R2R) production process supporting LED Linear™ Tj Away thin flexible circuit board technology.

Specification

Power
12W/M
Color Temperature
TW 2200K - 4000K
Light Source Type
LED
Lumen Output
250LM/M
Finishing
WHITE
IP Rating
IP67
Color Rendering
CRI 95
Driver
0-10V Driver

See more

IGUZZINI
WALLWASHER
OUTDOOR LIGHTING

Direct light luminaire, designed for use with RGBW LED light sources, 48Vdc DMX512-RDM dimmable with search and addressing function. Ceiling, wall or support installation. Consisting of body and supports for installation to be ordered separately. Body in extruded aluminium, with die-cast aluminium end caps complete with silicone gaskets and subjected to a multi-step pre-treatment process,

PUK
FLOODLIGHT
OUTDOOR LIGHTING
Floodlight for outdoor installation on a façade/wall, with U shape fixing bracket allowing vertical adjustment of +90° / -40°. Phospho-chromatised and polyester powder coated die-cast copper-free aluminium base and head, tempered safety glass, moulded silicone gaskets, with screws in stainless steel. Built-in LED driver, with 1 x CREE “XHP35” LED. IP66 rating.
PROLICHT
RECESSED DOWNLIGHT
INDOOR LIGHTING

Rotatability 350°, pivotability 30° · Series compatible with each other, uniform cutout diameter · Weight: 0.67 grams · 2 powder-coated color options · RAL colors on request · Dimmability depends on the ballast · Direct light colors: optionally 2700K, 3000K, 3500K or 4000K. · CRI > 90 · MacAdam: 3 · IP protection type IP65 · Height: 122 mm · Diameter: 108 mm

IGUZZINI
RECESSED DOWNLIGHT
INDOOR LIGHTING

Round recessed luminaire with contact frame. Fixed version. The LED is set back to minimize glare . The main body is made of die-cast aluminium with a radiant surface that guarantees optimum heat dissipation. Metallised, thermoplastic, high definition reflector - wideflood optic. Structure with die-cast aluminium external contact frame with a single white finish. The internal ring is made of thermoplastic available in a range of painted and metallised finishes. Safety glass included.
