LED LINEAR

LED STRIP

OUTDOOR LIGHTING

VARIOLED RGB LD15

Pixelized light line produced to the desired length with IP67 connectors on both ends for fast indirect facade lighting installations. Suitable with 10 different optics. Delivered ready to use with an IP67 connector on both ends and can be easily installed via clips or mounting profiles. The aluminium profile is used for thermal management, so that even powerful LED strips with up to 25W/M. The polyurethane encapsulation ensures an IP67 rating and high resistance against salt water and UV radiation by a clear polyurethane encapsulation.

Specification

Power

15W/M

Color Temperature

RGB

Light Source Type

LED

Lumen Output

480LM/M

Finishing

WHITE

IP Rating

IP67

Color Rendering

CRI 90

Driver

DMX 512

LED LINEAR

SURFACE LINEAR LIGHT

OUTDOOR LIGHTING

Luminaire with 45° adjustable head with a clear encapsulation and reflectors for general lighting applications. Polyurethane is utilized in XOOLUM to make it more resistant to impact from salt water UV-light and solvents. Modular mounting and lighting scenery thanks to its LEDs-Click technology enabling a 45° tilt of the luminaire head. Appealing form factor of 25.4mm*31mm which blends easily in any architectural concepts.

NEKO

ADJUSTABLE DOWNLIGHT

INDOOR LIGHTING

Round recessed downlight made of die-cast aluminium with white powder-coating finish (RAL 9016) and white reflector; 0-10V Dim Driver; System Power 15W; measurements Ø110mm x 131mm; ceiling cutout of Ø100mm with a narrow mounting trim; ceiling thickness 1-25mm; rotation 355° and pivot max. 30°; CCT 3000K with a System luminous flux of 1150lm; high color rendering at an index of CRI90; after a lifetime of 50000h L80B10 min. 80% of the luminous flux with energy efficient CITIZEN LED Chips; 5 years

DALITEK

CONTROL SYSTEM

6 channels 10A/CH switch output, 6 channels 0-10V control signal. Switch relays and 0-10V channels can be controlled separately. 220V ± 10% 50Hz Single phase 0.1A. Phase-independent. Control input: 1 × RS485 network serial port input; 1 × AUX dry contact input. Internal control: Build in programmable logic controller. Network DC power: 90mA DC12V. Presets scenes: 96 (no loss of information due to power failure. DIN rail installation
