Product Detail | Bloxlimited

IGUZZINI

SURFACE MOUNTED DOWNLIGHT

INDOOR LIGHTING

PALCO SURFACE QC42

Miniaturised adjustable spotlight for surface installation. Spotlight body with a die-cast aluminium dissipation system - cast zamak rotation unit - shaped steel fixing plate - thermoplastic surface cover base with stainless steel locking mechanism. The swivel joints allow the spotlight to be rotated by 360° and tilted by 90°. The set back position of the optic unit guarantees a high level of visual comfort with a thermoplastic high definition lens. Ballast not included, available with separate code.

Specification

Power

8.1W

Color Temperature

2700K

Light Source Type

LED

Lumen Output

450LM

Finishing

WHITE

IP Rating

IP20

Color Rendering

CRI90

Driver

ON/OFF DRIVER

IGUZZINI

SPOTLIGHT

OUTDOOR LIGHTING

Spotlight designed to use LED lamps and a Wide Flood optic. The optical assembly and base is made of EN1706AC 46100LF aluminium alloy and subjected to a multi-step, pre-treatment process, in which the main phases are degreasing, fluorozirconation (a protective surface film) and sealing (with a nano-structured silane layer). The following painting stage consists of a primer and a liquid acrylic paint, cured at 150°C, with a high level of weather and UV ray resistance. 5 mm thick tempered sodium-calcium closing glass. Double adjustability allows a 360° rotation about the vertical axis and 90° tilting relative to the horizontal plane. The ingress protection degree is IP66,IK07.

LINEALIGHT

WALLWASHER

OUTDOOR LIGHTING

Single emission lines for outdoor application. The warm white LED light source with a medium wide flood light distribution is composed of 12 powerled LEDs. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68; the total weight is of 1.020 kg. The power supply cable is included and features a 0.250 m length. The device features protection class II and can be floor-mounted with an outer casing, code 99762 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.

PHOS

SUSPENDED PENDANT LIGHT

INDOOR LIGHTING

ORBA INTERIOR PENDANT

Utilising our bespoke low voltage cable, drop tube versions can be made of the Screw, Puck, Wiring Housing, Spring, BESA

and Track options. The length of the cable can be supplied in bespoke lengths up to 2m.

SPARK

LED NEON TUBE

INDOOR LIGHTING

Flexible Slim Neon strip Horizontal bend available CCT from 2700K, 3000K and 4000K. Able to work with dimming and non-dimming driver. Accessories come with end cap, aluminium clip, flexible profile or rigid aluminium profile.

DIMENSION : (L)1000*(W)4*(H)10mm
