PICROL_86407W00

Indoor mini downlight made of brass chrome finish with a diffused light distribution. The ingress protection degree is IP44.

Specification

Power
1W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
111LM
Finishing
CHROME
IP Rating
IP44
Color Rendering
CRI 80
Driver
ON/OFF DRIVER

See more

LINEALIGHT
SPOTLIGHT
OUTDOOR LIGHTING


WE-EF
SPOTLIGHT
OUTDOOR LIGHTING
IP66, Class III. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. Electronic control gear in separate gear box (constant current), prewired. Gearbox to be ordered separately. One factory installed flange plug M8 x 1.5. Cable length 3.0 m. CAD-optimised optics for superior illumination and glare control. Factory-installed LED circuit board. Maximum one internal optical accessory possible. To be specified at time of ordering.
LINEALIGHT
UP/DOWN WALL LIGHT
OUTDOOR LIGHTING
Single emission uplights for outdoor application. The warm white LED light source with a flood light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a black finish, processed by means of open pore anodizing + powder coating; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP68; the total weight is of 0.5 kg. The power supply cable is included and features a 1 m length. The device features protection class III and can be floor-mounted with an outer casing, code 99856 (for concrete or masonry). Compliant with the EN 60598-1 standard and its specific provisions.
LINEALIGHT
SURFACE LINEAR LIGHT
OUTDOOR LIGHTING
Single emission lines for outdoor application. The RGBW - 3000 K LED light source with a spot light distribution is composed of 12 powerled LEDs. Luminaire body is made of aluminium 6060 and features a anodised aluminumfinish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silkscreening treatment. The ingress protection degree is IP67; IK10.
