LUMASCAPE

Single emission downlights for indoor application. The super warm LED light source with a spot light distribution is composed of 1 powerled LEDs. The device body is made of aluminium 6026 and features a embossed white ral 9003 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.128 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.170 m length. The device features protection class III and can be ceiling-mounted, with a 35 mm diameter hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.

Round recessed spotlight in die-cast aluminium; 1 lamp; surface black; 360° rotatable and 30° tiltable; installation without tools in mounting set due to patented ball catch system; round installation housing; with trim jet black; for installation in soft acoustic ceilings; suitable for ceiling thickness of 25-40 mm. The ingress degree of protection from below IP40 (from above IP20).

Single emission downlights for indoor application. The warm white LED light source with a spot light distribution is composed of 3 powerled LEDs. The device body is made of plaster and features a white finish; the diffuser is made of ABS. The ingress protection degree is IP20; the total weight is of 0.500 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.170 m length. The device features protection class III and can be ceiling-mounted, with a 160 x 90 mm hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.

Die-cast aluminium housing. Pre-treated before powder coating ensuring high corrosion resistance. 6 mm thick front ring in grade 316 stainless steel or aluminium. Single cable entry, through wiring upon request. Stainless steel fasteners in grade 304 with zinc flake coating (ZFC). Durable silicone rubber gasket. High-efficiency PMMA lens. Clear or frosted toughened glass. Integral control gear for HA-60036, HA-60037, HA-60049, HA-60050, HA-60196, HA-60197, HA-60209, HA-60215, HA-60295, HA-60296, HA-60305, HA-60306. Remote driver, remote box IP-rated and recessing box is included for HA-60385, HA-60386, HA-60395, HA-60396. Recessing box in high-density polyethylene is included. Suitable for walk-over with a maximum load of 200 kg
