UNIOS

RECESSED DOWNLIGHT

OUTDOOR LIGHTING

ION RM_IONR0103.WW27.N-UN.DAR020.0400.01

Available in 4 sizes, an extensive range of accessories and 15,000+ customisations, the ION R Downlight is an outstanding contender for all lighting needs. With 2 models, Standard and Wallwasher, the ION R Downlight can be specified for both horizontal and vertical lighting needs.

Specification

Power

15W

Color Temperature

2700K

Light Source Type

LED

Lumen Output

1119LM

Finishing

WHITE

IP Rating

IP54

Color Rendering

CRI90

Driver

DALI Driver

IGUZZINI

PENDANT

INDOOR LIGHTING

Miniaturised pendant system with LED lamp and including an adapter for installation on a 48V low voltage Filorail track ideal for zenithal accent lighting. The adapter is made of a thermoplastic material and includes a driver circuit with PWM(Pulse with modulation) technology.The integrated PWM technology allows the light intensity to be adjusted by creating the effect of a dimmed light without altering the quality of the light.

LINEALIGHT

CEILING LIGHT

INDOOR LIGHTING

Single emission ceiling lights for indoor application. The warm white LED light source with a wide flood light distribution is composed of 24 powerled LEDs. The device body is made of aluminium 6060 and features a embossed white ral 9003 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP40; the total weight is of 4.3 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.1 m length. The device features protection class III and can be ceiling-mounted, with a 912 mm diameter hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.

IGUZZINI

ADJUSTABLE DOWNLIGHT

INDOOR LIGHTING

Fixed linear module with 5 optical elements complete with adapter for installation on Superrail LV track. The thermoplastic adapter includes the DC/DC driver circuit with DALI dimmable function. The integrated «Powerline» technology allows each light module inserted on the track to be adjusted independently. Fixed optics with high-definition Opti-Beam reflectors in metallised thermoplastic. Despite the minimum dimensions of the product, the patented technology of the optical system guarantees an

XAL

LINEAR DOWNLIGHT

INDOOR LIGHTING

Rectangular recessed multi-downlight made of die-cast aluminium; installation without tools in mounting set due to patented ball catch system; rectangular installation housing; for trimless installation in plasterboard ceilings; suitable for ceiling thickness of 12.5/15/20/25 mm; equipped with six medium round light elements; symmetrical light distribution with precise radiation characteristic, beam angle 33°; high quality reflector with micro-faceted, aluminum-vaporised surface; chrome reflector; UGR ≤ 10; VDU compatible workplace luminaire according to DIN EN 12464-1; luminance above 65° ≤ 3000 cd/m²; passive cooling of the LEDs through improved heat sink geometry; light colour 3000 K; binning initial MacAdam ≤ 3 SDCM; CRI ≥ 90; min. 90% of luminous flux after 50000 operating hours; energy-efficient high power LEDs with very good colour rendering; degree of protection IP20; PC2; incl. converter, non dimmable; through wiring connection box, 3-pole or 5-pole, available as an accessory; accessories are listed separately; light source not replaceable; control gear replaceable by an authorized professional; clank-free
