LINEALIGHT

Ceiling-mounted luminaire with 10 optic elements for LED lamps - fixed optics with metallised thermoplastic high definition OptiBeam reflectors. Despite the ultracompact size of the product, the patented technology of the optic system guarantees an efficient luminous flux and a high level of controlled glare visual comfort. Extruded aluminium main body and technical dissipation unit - shaped steel fixing plate.

Projector to be installed on threephase track with LED light source. Built-in 220-240V, 50-60Hz power supply. All finishes come with black track adapter, arm and back of the head. In the “all white” versions the track adapter, arm and back of the head come in white. The display is always offered in high loss technical black anti-glare finish. For other finishes, please consult us.

The Relay Contact Module is an ultra compact DINrail mounted unit with connections for four relay outputs and an M-BUS network. Each feed through relay can switch 5A with a maximum module load of20A.Each of the four relays are individually addressable and are all synchronised to zero crossing of the ACsine wave referenced to the module mains supply. This minimises the potential arc damage that can occur to the contacts.

Luminaire made of aluminium alloy, aluminium and stainless steel Antique glass. Mounting plate with 3 fixing holes ø 9.2 mm. Angle 120° · Pitch circle ø 138 mm. 2 cable entries for through-wiring of mains supply cable ø 7-10,5 mm, max. 3 G 1.5@ 3-pole plug connection with connecting terminal and earth conductor terminal 2.5@ LED power supply unit, 220-240 V x 0/50-60 Hz, DC 198-280 V, Safety class I, Protection class IP 44, Protected against granular foreign bodies, > 1 mm and splash water, c – Conformity mark.
