IGUZZINI

RECESSED LINEAR LIGHT

OUTDOOR LIGHTING

LINEALUCE BW33

Recessed luminaire applicable to the floor or ground, designed for fitting monochrome white LED sources, for illumination, adjustable optic, with DALI dimmable incorporated electronic control gear. The round frame has a diameter D200 mm the body and frame are made of AISI 304 stainless steel with sodiumcalcium extra clear glass, thickness 15 mm. Stainless steel body coated with black paint. The luminaire is secured to the outer casing by means of two TORXtype screws that ensure proper anchoring. Inclusive of LED circuit, methacrylate lens and black plastic cover. The ingress protection degree is IP67,IK09.

Specification

Power

13W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

936LM

Finishing

GREY

IP Rating

IP66

Color Rendering

CRI80

Driver

DALI Driver

LUCI

LINEAR LIGHT

INDOOR LIGHTING

This RIMIT sa is innovative design, featuring a 9mm square shape and three radiant surfaces, creates an immersive three-dimensional lighting experience.'The circular shape creates a soft, wide light distribution. Light distribution is wide due to the round shape of the fixture, resulting in a shadow-free gradient of light.

BEGA

WALL LIGHT

OUTDOOR LIGHTING

Luminaire made of aluminium alloy, aluminium and stainless steel. Opal glass. Silicone gasket. Mounting plate with 2 fixing holes ø 5.2 mm · 70 mm spacing, 1 cable entry for mains supply cable up to ø 10,5 mm max. 3 × 1,5@ Plug connection. Connecting terminal 2.5@ Earth conductor connection. LED power supply unit 220-240 V x 0/50-60 Hz, DC 198-280 V. Safety class I, Protection class IP 44, Protected against granular foreign bodies, > 1 mm and splash water. Impact strength IK06. Protection against mechanical impacts < 1 joule, r – Safety mark, c – Conformity mark.

LUCE & LIGHT

SPOTLIGHT

OUTDOOR LIGHTING

Ginko 1.0 Outdoor surface mounted projector light (ceiling, wall, ground, spike), housing made of ANTICORODAL 6082 low-copper-content aluminium alloy for excellent resistance to corrosion, made entirely on a CNC lathe. Bracket in AISI 316L stainless steel, tumble finished and painted (painted version), body made of brass, produced entirely on a CNC lathe. Bracket made of brass. Optics available: 12°, 19°, 36°, sharp 38°, 58°, 16°x36°, 36°x16°, 12°, 19°, 36°, 58°. IP66, IK07.
