IGUZZINI

TRACKLIGHT

INDOOR LIGHTING

ROBIN_QV49

Miniaturised adjustable spotlight with adapter for installation on 48V low voltage track. Made of die-cast aluminium with passive dissipation system. The adapter made of a thermoplastic material includes the DC/DC driver circuit with a DALI power line dimmable function. Integrated «power line» technology allows each spotlight on the track to be adjusted separately. The swivel joints allow the spotlight to be rotated by 360° and tilted by 160° with the option of installing the spotlight on a 48V track in both an "up" and "down” position. The set back position of the optic unit guarantees a high level of visual comfort.

Specification

Power

11.3W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

540LM

Finishing

BLACK

IP Rating

IP20

Color Rendering

CRI90

Driver

DALI DRIVER

IGUZZINI

ADJUSTABLE DOWNLIGHT

INDOOR LIGHTING

Round recessed luminaire with contact frame. Adjustable version that tilts by a maximum of 30°. The main swivel body is made of die-cast aluminium with a radiant surface that guarantees optimum heat dissipation. Metallised, thermoplastic, high definition reflector - flood optic. Structure with die-cast aluminium external contact frame with a single white finish. Steel rotating parts. The ring inside the swivel body is made of thermoplastic available in a range of painted and metallised finishes. Safety glass included Quick and easy tool free assembly. IP20

SPARK

TRACKLIGHT

INDOOR LIGHTING

Track Adjustable Spotlight luminaire body made of aluminium housing with white powder coated finish. Black finish and honeycomb accessory available upon request. It come with different types of bean angles.

LUCE & LIGHT

SPOTLIGHT

OUTDOOR LIGHTING

projector for outdoor applications; surface mounted (ceiling, wall, ground, spike); Power consumption: 10W; Power supply: 24Vdc; Lumen output at source: 1096 lm (3000K, 10W, CRI 80); Delivered lumen output: 750 lm (3000K, 42°, 10W, CRI 80); 1 high power density COB LED, 2-step MacAdam, 50 000h L95 B10 (Ta 25°C); LED colour: 3000K; Optics: 8°: optical system consisting of a high-efficiency TIR lens combined with a high-quality technical filter; CRI Colour Rendering Index: 80
