FORMALIGHTING

RECESSED LINEAR LIGHT

OUTDOOR LIGHTING

3501BT11-803000DA84

Linear recessed walk-drive over uplighters with trim in stainless steel (AISI 316) and light housing in extruded aluminium. Light trim inclusive of toughened safety glass, weatherproof durable silicone and external screws of stainless steel. Thermoplastic recessed box included additional recessed box for installation in concrete available upon request. Equipped with hard wire rubber cable.

Specification

Power

2440W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

67478.4LM

Finishing

STAINLESS STEEL

IP Rating

IP67

Color Rendering

CRI 80

Driver

ON/OFF DRIVER

WE-EF

INGROUND UPLIGHT

OUTDOOR LIGHTING

IP69. IK10+. Stainless steel construction including PCS hardware. Safety glass lens; max. load 5 tonnes. Luminaire can be driven over at low speed. Silicone rubber gasket. Factory-sealed termination chamber complete with cable gland and 1.5 m of flexible PVC free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC One LED Concept. Luminaire installation blockout and sealable junction box included in supply.

LINEALIGHT

ADJUSTABLE DOWNLIGHT

INDOOR LIGHTING

LINEALIGHT

CEILING LIGHT

INDOOR LIGHTING

Single emission ceiling lights for indoor application. The warm white LED light source with a wide flood light distribution is composed of 1 arrayled LEDs. The device body is made of aluminium 6060 and features a embossed white ral 9003 finish, processed by means of powder coating The device body is made of aluminium 6060 and features a 5g 9005 black finish, processed by means of powder coating; the diffuser is made of extra clear glass. The ingress protection degree is IP40; the total weight is of 0.50 kg. The device features protection class I and can be ceiling-mounted. Compliant with the EN 60598-1 standard and its specific provisions.
