Housing of corrosion‑resistant die‑cast aluminum AlSi12, double polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass flush with frame, anti‑reflective coating from 1 side, for loads up to max. 5000 kg (according to IEC / EN 60598‑2‑13), silicon gasket, cover frame and closure with 6 stainless steel screws, cable gland: M20, connecting terminal: 3 pole, highly efficient anodized rotationally symmetrical reflector, lockable, tilt range: 0‑20°, lockable, with Heatslide mechanism for optimal heat dissipation, 0,8 m cable H07RN‑F3G1, integral driver (AC), CRI > 80, 3 SCDM, service life L80/B20 > 50.000 h, Beam angle (fwhm): 42°, luminous flux: 1551 lm, wattage: 19 W, delivered lumens 82 lm/W, protection type IP68, protection class I, impact resistance IK10, dimensions: Ø 220 mm, width 152 mm, weight 3.9 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE mark.

Outdoor double emission wall lights come with a diffused light distribution composed of 21 top led LEDs. Luminaire body is made of aluminium and features a text white RAL 9003 finish, processed by means of coating; the diffuser is made of glass. IP65, IK06

DIMENSION : Ø126*H107

Single emission uplights for outdoor application. The warm white LED light source with a radial mono-directional emission light distribution is composed of 1 arrayled LEDs with CCT of 3000 K and a CRI 80; the source luminous flux is 685 lm, with a 114.2 lm/W nominal luminous efficacy. The device body is made of aluminium and features a grey ral 9006 finish, processed by means of coating. The ingress protection degree is IP67, IK09.

The Eyeconic Mini Trim Square Adjustable is a recessed, directional downlight with a 62x62mm square bezel and features a beautifully sculpted anti-glare baffle. 360° rotation,28° Tilt
