3506BB12-803014DA29
Round ceiling luminaire with trim, light body and ring in cast aluminium. Central housing in aluminium extrusion, with toughened safety glass, weatherproof durable silicone gasket and external screws made of stainless steel. Front cover is designed to avoid accumulation of dust and water. Electrical installation includes double cable entry.

Specification

Power
15.4W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
1936.8LM
Finishing
GREY
IP Rating
IP65
Color Rendering
CRI 80
Driver
ON/OFF DRIVER

See more

LINEALIGHT
RECESSED DOWNLIGHT
INDOOR LIGHTING
Single emission downlights for indoor application. The warm white LED light source with a spot light distribution is composed of 1 arrayled LEDs. The device body is made of uv resistant polycarbonate and features a embossed black ral 9005 finish, processed by means of liquid painting; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.2 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.15 m length. The device features protection class III and can be ceiling-mounted, with a 65 x 65 mm hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.
LINEALIGHT
SURFACE MOUNTED DOWNLIGHT
INDOOR LIGHTING

double emission pendant luminaires for indoor application. The warm white LED light source with a diffused light distribution is composed of 64 topled LEDs with CCT of 3000 K and a CRI 80; the source luminous flux is 2414 lm, with a 150.9 lm/W nominal luminous efficacy. The device body is made of iron and features a embossed white ral 9003 finish, processed by means of coating; the diffuser is made of pmma; the mounting frame is made of iron, with a zinc finish, processed by means of washing. The ingress protection degree is IP20; the total weight is of 1.4 kg. The total absorbed power is 20 W. The device features protection class II and can be wall lights-mounted. Compliant with the EN 60598-1 standard and its specific provisions

LINEALIGHT
CEILING LIGHT
INDOOR LIGHTING
Double emission ceiling lights for indoor application. The warm white LED light source with a diffused light distribution is composed of 78 topled LEDs. The device body is made of aluminium 6060 and features a embossed white ral 9003 finish, processed by means of powder coating; the diffuser is made of pmma. The ingress protection degree is IP40; the total weight is of 8.52 kg. The device features protection class I and can be wall lights or ceilingmounted. Compliant with the EN 60598-1 standard and its specific provisions.
CUSTOMIZED
TABLE LAMP
OUTDOOR LIGHTING

Decorative Outdoor table top or hanging light illuminate your back porch, deck or living room with a warm and inviting glow. The unique color and shape of these lanterns add a stylish detail to any room providing a touch of elegance and sophistication. Suitable for Indoor or Outdoor application.
