EWO

Luminaire with 45° adjustable head with a clear encapsulation and reflectors for general lighting applications. Polyurethane is utilized in XOOLUM to make it more resistant to impact from salt water UV-light and solvents. Modular mounting and lighting scenery thanks to its LEDs-Click technology enabling a 45° tilt of the luminaire head. Appealing form factor of 25.4mm*31mm which blends easily in any architectural concepts.

surface-mounted light · Photometric covers optional: Opal (PMMA), Microprism,Crystal or Industrial · invisible weld seams · no visible screws · RAL colors on request ·

28 colors possible · 240 Volt, 50/60 Hz · not dimmable · 3-pole terminal block ·Direct light colors: optionally 2700K, 3000K, 3500K or 4000K. · LED board coatedwith high-reflective material · CRI > 90 · MacAdam: 3 · 50,000 hours lifespan ·Flicker-free operation with suitable electronic ballast ·

Suspended luminaire come with frosted PMMA cover with lateral light emission edge. Soft light effect with complete glare illumination. With direct / indirect light distribution. Luminaire body of extruded aluminium profile. End caps of die-cast aluminium. Luminaire body white powder-coated. .Dimensions L1200*W200*H45MM

Luminaire made of aluminium alloy, aluminium and stainless steel Crystal glazing, Mounting plate with 3 fixing holes ø 5.5 mm. Angle 120° · Pitch circle ø 85 mm, 2 cable entries for through-wiring of mains supply cable ø 7-10,5 mm, max. 3 G 1.5@. Connecting terminal 2.5@ with plug connection. Earth conductor connection. LED power supply unit, 220-240 V x 0/50-60 Hz, DC 176-264 V. DC Start ≥ 198 V, Safety class I Protection class IP 44, Protected against granular foreign bodies > 1 mm and splash water, r – Safety mark, c – Conformity mark.
