LIGMAN

WALL LIGHT
INDOOR LIGHTING
NYB-30222-O-W30
Luminaire made of die-cast aluminium end-caps and extruded aluminium profile with powder coating. Single cable entry, stainless steel fasteners in grade 316. PMMA diffuser with Opal (UGR <19) and micro prismatic (UGR <13) options for better glare control. Up and down light distribution options. Passive thermal management, integral control gear. Wireless control available through Bluetooth connection. Daylight and occupancy sensor options. Emergency module (1 or 3 hours) is available upon request with 3 options (BASIC, SELF-TEST, PRODALI). IP20.

Specification

Power
25W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
2957LM
Finishing
ALUMINIUM
IP Rating
IP20
Color Rendering
CRI80
Driver
ON/OFF DRIVER

See more

XAL
SURFACE MOUNTED DOWNLIGHT
INDOOR LIGHTING

Rectangular surface mounted multi-downlight made of aluminium; luminaire housing can be attached to mounting plate without tools by interlock; converter integrated into luminaire housing; surface traffic white powder coated; equipped with six wide flood round light elements; symmetrical light distribution with precise radiation characteristic, high quality reflector with micro-faceted, aluminum-vaporised surface; Reflector chrome; passive cooling of the LEDs through improved heat sink.

LINEALIGHT
WALL LIGHT
OUTDOOR LIGHTING
Single emission lines for outdoor application. The super warm white LED light source with a asymmetric wallwasher light distribution is composed of 6 powerled LEDs with CCT of 2700 K and a CRI 80; the source luminous flux is 1692 lm, with a 128.2 lm/W nominal luminous efficacy. The device body is made of aluminium 6060 and features a anodised aluminum finish, processed by means of 20 µm anodizing; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP67; the total weight is of 1.1 kg. The total absorbed power is 14.5 W. The power supply cable is included and features a 0.2 m length.
SPARK
UP/DOWN WALL LIGHT
OUTDOOR LIGHTING

Up/down surface mount wall light for outdoor application. Luminaire made of aluminium housing and tempered glass cover. Color temperature from 3000K to 6500K. Various beam angle 15°/24°/38°/45°/60°. IP65

DALITEK
CONTROL SYSTEM
CONTROL SYSTEM

The module realizes the opening and closing control ofsixcircuits by controlling six20A single pole single throw (SPST) relays, and various logic timing control can berealized through configuration. The module has an internal temperature sensor to monitor the operating temperature to ensure safety.The module is compatible with other a dry contact input module.The module can form a control system with panel, clock, sensor and other equipmentthrough RS485 bus.
