LED LINEAR

SURFACE LINEAR LIGHT

OUTDOOR LIGHTING

NANO WHITE IP67_15° X 40°

XOOLUX NANO is a minimalistic and flat luminaire designed primarily for grazing applications. The updated IP classification now stretch to IP67, meaning water resistance and suitable for outdoor use. Nano lens optics allow precise control of the light distribution while maximizing lumen output and minimalizing color over angle for crisp and homogeneous grazing. Different light distributions makes Xoolux Nano the goto product for grazing as well as delicate flooding applications. Further improving flexibility is achieved through the use of mounting clips, enabling tilt angles every 5° increments from 0° to 45°.

Specification

Power

10W/M

Color Temperature

3000K

Light Source Type

LED

Lumen Output

570LM/M

Finishing

BLACK

IP Rating

IP67

Color Rendering

CRI95

Driver

ON/OFF DRIVER

IWASH

WALLWASHER

INDOOR LIGHTING

iWash is a minimalistic linear profile creating a asymmetric light effect for a uniform illumination of surfaces and shelves due to its narrow opal or transparent PMMA design cover. Perfectly suitable to be mounted under shelves, in ceilings or in furniture. iWash can be equipped with a single or double LED strip and delivers a maximum lumen package of 1100 lumens per meter from carefully selected binning-free two-step MacAdam’s ellipses SMD LEDs with a choice of 3 standard colour temperatures (2700K, 3000K, 4000K). iWash is powered on 24Vdc constant voltage.

MEYER

PROJECTOR LIGHT

OUTDOOR LIGHTING

Housing made of die‑cast aluminum AlSi12, polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass, anti‑reflective coating from 1 side, dark screenprint, silicon gasket, closure with 4 stainless steel screws, powder coated aluminum mounting bracket with tilt scale: 2 drilled holes Ø 8.5 mm, spacing 70 mm, 1 centre hole Ø 17 mm, tilt range: 120°, cable gland: M20, connecting terminal: 3 pole, highly efficient anodized rotationally symmetrical reflector with matt finish, integral driver (AC/DC), CRI > 80, max 2 SDCM, service life L90/B10 > 50.000 h, Beam angle (fwhm): 48° / 52°, luminous flux: 5288 lm, wattage: 46 W, delivered lumens 116 lm/W, protection type IP67, protection class I, impact resistance IK08, windage area 0,04 m², dimensions (L×H×W): 190 × 160 × 140 mm, weight 2.6 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE and ENEC marks. Customized solutions and modifications are possible: Special ral, db or ncs colours as polyester powder coat, luminaires in 2700 K and other colour temperatures and versions for high ambient temperature.

LUMASCAPE

UNDERWATER LIGHT

OUTDOOR LIGHTING

LINEALIGHT

RECESSED DOWNLIGHT

INDOOR LIGHTING

Single emission downlights for indoor application. The warm white LED light source with a medium wide flood light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a white finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44.
