LINEALIGHT

LED STRIP
OUTDOOR LIGHTING
80403

Single emission led strip for outdoor application. The RGBW - 3000K LED light source with a diffused light distribution is composed of 132 topled LEDs with CCT of RGB-W 3000K. The device body is made of technopolymer and features a white finish; the diffuser is made of pu. The ingress protection degree is IP67; the total weight is of 0.103 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 1(M)x0,25 m 1(F)x0,25 m length.

Specification

Power
16.5W/M
Color Temperature
RGBW 3000K
Light Source Type
LED
Lumen Output
361LM/M
Finishing
WHITE
IP Rating
IP67
Color Rendering
CRI 80
Driver
ON/OFF DRIVER

See more
