DELTALIGHT

RECESSED DOWNLIGHT

OUTDOOR LIGHTING

DEEP RINGO X 92733 W

Deep Ringo is the most elaborate of the family, offering LED and halogen solutions, for use in both dry and wet areas. Deep Ringo also offers a ribbed version that reduces the glare thanks to its cascading transition from light source to ceiling. Furthermore Deep Ringo can also be used as light unit in our ▲IR range, a toolset that combines light and ventilation in one.

Specification

Power

12W

Color Temperature

2700K

Light Source Type

LED

Lumen Output

799LM

Finishing

WHITE

IP Rating

IP65

Color Rendering

CRI90

Driver

ON/OFF DRIVER

MEYER

POLE LIGHT

OUTDOOR LIGHTING

Housing made of corrosion‑resistant die‑cast aluminum AlSi12, polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass, anti‑reflective coating from 1 side, dark screenprint, silicon gasket, closure with 3 stainless steel screws, for installation on poles Ø 60 ‑ 100 mm, tiltable base made of powder coated aluminum, 2 drilled holes Ø 9 mm, spacing 95 mm, 1 centre hole Ø 13.5 mm, tilt range: 90°, 360° adjustable, cable gland: M20, connecting terminal: 3 pole, focusable projection lens for precise light control and sharp‑edged image projections, integral driver (AC/DC), CRI > 80, Beam angle (fwhm): 41°, luminous flux: 1483 lm, wattage: 55 W, delivered lumens 27 lm/W, protection type IP65, protection class I, impact resistance IK08, windage area 0,076 m², dimensions: Ø 215 mm, width 390 mm, weight 8 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE mark.

LUCI

WALLWASHER

INDOOR LIGHTING

KIWA MONO new design powerful wall grazing light with lumen output up to 3000lm. Super low power consumption with impressive light extension. Ultra-compact at just 17*18.5mm, it is inconspicuously blends into any space. Luminaire material aluminium and polycarbonate. IP20 for Indoor application.

LINEALIGHT

RECESSED DOWNLIGHT

INDOOR LIGHTING

Single emission recessed downlights for indoor application. The warm white LED light source with a wide flood light distribution is composed of 1 arrayled LEDs. The luminaire body is made of technopolymer and features a white finish; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP20.

LINEALIGHT

SURFACE MOUNTED DOWNLIGHT

INDOOR LIGHTING

double emission pendant luminaires for indoor application. The warm white LED light source with a diffused light distribution is composed of 64 topled LEDs with CCT of 3000 K and a CRI 80; the source luminous flux is 2414 lm, with a 150.9 lm/W nominal luminous efficacy. The device body is made of iron and features a embossed white ral 9003 finish, processed by means of coating; the diffuser is made of pmma; the mounting frame is made of iron, with a zinc finish, processed by means of washing. The ingress protection degree is IP20; the total weight is of 1.4 kg. The total absorbed power is 20 W. The device features protection class II and can be wall lights-mounted. Compliant with the EN 60598-1 standard and its specific provisions
