WE-EF

INGROUND UPLIGHT

OUTDOOR LIGHTING

ETC340_185-7805

RGBW Colour Changer. IP67. Class I. IK10+. Stainless steel construction including PCS hardware. Safety glass lens, max. load 5 tonnes. Luminaire can be driven over at low speed. Silicone rubber gasket. Factory-sealed termination chamber with cable gland and 0.5 m of flexible PVC-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC One LED Concept. 20° tiltable and 355° rotatable. LED circuit board with WEEF Colour Boost Technology. DMX Interface. For other control interface options to suit specific project requirements, contact WEEF. Luminaire installation blockout and sealable junction box included in supply

Specification

Power

25W

Color Temperature

RGBW

Light Source Type

12 LEDS

Lumen Output

1742LM

Finishing

STAINLESS STEEL

IP Rating

IP67

Color Rendering

CRI 20

Driver

DMX Driver

LINEALIGHT

RECESSED DOWNLIGHT

INDOOR LIGHTING

Single emission downlights for indoor application. The warm white LED light source with a wide flood light distribution is composed of 1 arrayled LEDs. The device body is made of aluminium 6026 and features a embossed black ral 9005 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.480 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.300 m length. The device features protection class III and can be ceiling-mounted, with a 105 mm diameter hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.

LUCE & LIGHT

BOLLARD

OUTDOOR LIGHTING

Outdoor Surface mount bollard made of ANTICORODAL EN AW 6082 low-copper-content aluminum alloy for excellent resistance to corrosion. Screen in serigraphed, tempered extra-clear glass. Accessories come with honeycomb louvre. Pole available in 500mm, 800mm and 1100mm 3 different height . IP66, IK08,

BEGA

BOLLARD

OUTDOOR LIGHTING

Garden and pathway luminaires for glare-free illumination of surfaces from low mounting heights. Luminaire made of aluminium alloy, aluminium and stainless steel. IP65, IK06.
