WE-EF

SPOTLIGHT

OUTDOOR LIGHTING

FLC230_139-1846

IP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG Controlled Compression Gasket. Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. OLC One LED Concept. For 2200 K version available on request, except [EES] distribution.

Specification

Power

52W

Color Temperature

3000K

Light Source Type

12 LEDS

Lumen Output

5800LM

Finishing

GREY

IP Rating

IP66

Color Rendering

CRI 80

Driver

ON/OFF DRIVER

LUCI

LED STRIP

INDOOR LIGHTING

12mm diameter all-around luminous dotless line lighting Midpoint lead wire option for wall mounting 40 lengths up to 1009mm (one end) or 8 up to 509mm (midpoint), in 25mm increments

FORMALIGHTING

RECESSED DOWNLIGHT

INDOOR LIGHTING

Round or Square mounting trim in cast aluminium with spring for installation mounting on a ceiling thickness of 1-25mm. Luminaire body in cast alluminum. Easy relamping tool-free via removable lamp front ring. Available in two different sizes. Adjustable version tiltable vertically 0-40° and rotatable horizontally 350°.

LIGHTFORMS

SUSPENDED PENDANT LIGHT

INDOOR LIGHTING

Lightplane Linear is a compact and streamlined luminaire that features integral drivers along with a high impact satin diffuser lens. The fixture is available with several LED lamping options including multiple outputs and CCTs, tunable white and colour-changing RGB+White.
