WE-EF

SURFACE MOUNTED LIGHT
OUTDOOR LIGHTING
131-9513
Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone rubber gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Two cable entries. Optional 2200 K version up to max. 1050mA available. To be specified at time of ordering. Luminaire can be mounted for up or down lighting.

Specification

Power
12W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
1173.1LM
Finishing
ANTHRACITE GREY
IP Rating
IP66
Color Rendering
CRI 80
Driver
ON/OFF DRIVER

See more

PLATEK
INGROUND UPLIGHT
OUTDOOR LIGHTING

In-ground luminaire made of aluminium alloy body. Locking flange in AISI 316L stainless steel. A4 Stainless steel screws. Subjected to galvanic anodizing treatment divided into distinct phases: mechanical satin finishing, surface degreasing, anodic oxidation and final sealing. Installation of the recessed housing is cast concrete with a 20-30cm gravel soakaway. IP67, IK10

SPARK
ZOOMABLE DOWNLIGHT
INDOOR LIGHTING

Recessed adjustable Zoomable downlight come with snoot, luminaire body made of aluminium housing with white powder coated finish. Black finish available upon request.

IGUZZINI
SURFACE LINEAR LIGHT
OUTDOOR LIGHTING

Compact direct light luminaire using monochrome LEDs, DMX512-RDM dimmable (48Vdc), for ceiling, wall, or surface mounting. Made of extruded aluminium with die-cast end caps and silicone seals, treated for high weather and UV resistance. Features a 3mm transparent glass screen, integrated Warm White multi-LED plate, and DMX512-RDM driver (ballast sold separately). Includes PG11 connectors for pass-through wiring and methacrylate lens for flood optics. Complies with EN 60598-1 standards.

LINEALIGHT
RECESSED DOWNLIGHT
INDOOR LIGHTING
Single emission downlights for indoor application. The warm white LED light source with a flood light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.511 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.300 m length. The device features protection class III and can be ceiling-mounted, with a 92 x 92 mm hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.
