RING MEDIUM HP_101405_20W-28°
Floodlight for outdoor installation on a façade/wall, with 355° swivel base and allowing horizontal adjustment of +90° / -40°. Phospho-chromatised and polyester powder coated die-cast copper-free aluminium base and head, tempered safety glass, moulded silicone gaskets and o-rings, with screws in stainless steel. Swivel joint with graduated scale and mechanical aiming lock. Built-in LED driver, with 1 x CREE “XHP35” LED. IP66 rating.

Specification

Power
20W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
1950LM
Finishing
GREY
IP Rating
IP66
Color Rendering
CRI 90
Driver
DALI DRIVER

See more

LINEALIGHT
INGROUND UPLIGHT
OUTDOOR LIGHTING

Single emission wall lights for outdoor application. The super warm LED light source with a asymmetric wallwasher light distribution is composed of 1 array leds. Luminaire body is made of die-cast aluminium en ab - 46100 and features a black finish, processed by means of open pore anodizing + powder coating; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. IP68, IK10

SPARK
MAGNETIC TRACKLIGHT
INDOOR LIGHTING

48V Magnetic Track Linear Spot Module

DIMENSION : 172*22*25mm

PROLICHT
RECESSED DOWNLIGHT
INDOOR LIGHTING

MAGIQ is a family of sophisticated spot lighting that perfectly sets the scene for architecture and interior design. In addition to the existing MAGIQ WALLWASH module with its five integrated, well-known and innovative reflectors, which provide a wide, uniform light pattern in rooms with high ceilings, PROLICHT has designed MAGIQ HOLLOW WALLWASH as an addition to this range. The new development uses eight fully integrated MDB-W reflectors that are flush with the ceiling.

MEYER
PROJECTOR LIGHT
OUTDOOR LIGHTING
Housing made of die‑cast aluminum AlSi12, polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass, anti‑reflective coating from 1 side, dark screenprint, silicon gasket, closure with 4 stainless steel screws, powder coated aluminum mounting bracket with tilt scale: 2 drilled holes Ø 8.5 mm, spacing 70 mm, 1 centre hole Ø 17 mm, tilt range: 120°, cable gland: M20, connecting terminal: 3 pole, highly efficient anodized rotationally symmetrical reflector with matt finish, integral driver (AC/DC), CRI > 80, max 3 SDCM, service life L90/B10 > 50.000 h, Beam angle (fwhm): 12°, luminous flux: 4391 lm, wattage: 48 W, delivered lumens 91 lm/W, protection type IP67, protection class I, impact resistance IK08, windage area 0,04 m², dimensions (L×H×W): 192 × 162 × 140 mm, weight 2.16 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE and ENEC marks. Customized solutions and modifications are possible: Special ral, db or ncs colours as polyester powder coat, luminaires in 2700 K and other colour temperatures and versions for high ambient temperature.
