C-SFR-F22B-VB-24CC-40K-WM-108-90-12W-55.6

Aquaglo™ F22 series, the IP68 rated flexible LED neon, gives you unprecedented freedom in lighting design for indoor and outdoor underwater applications, featured with continuous glow, multiple color options, custom length, and two bending directions. As a professional underwater luminaire, it is UL 676 certified and resistant to rust, chlorine, UV proven by extensive tests, aiming to create the safe and cozy ambient out of your expectation.

Specification

Power
12W/M
Color Temperature
4000K
Light Source Type
LED
Lumen Output
470LM/M
Finishing
WHITE
IP Rating
IP68
Color Rendering
CRI 90
Driver
ON/OFF DRIVER

See more

LINEALIGHT
FLOODLIGHT
OUTDOOR LIGHTING

Single emission projectors for outdoor application. The warm white LED light source with a flood light distribution is composed of 2 arrayled LEDs .The luminaire body is made of die-cast aluminium en ab - 46100 and features a black finish, processed by means of open pore anodizing + powder coating; the diffuser is made of extra clear glass - tempered with a silk-screening treatment. The ingress protection degree is IP66, IK08.

LINEALIGHT
RECESSED DOWNLIGHT
INDOOR LIGHTING
Single emission downlights for indoor application. The warm white LED light source with a medium flood light distribution is composed of 1 arrayled LEDs. The device body is made of die-cast aluminium en ab - 46100 and features a embossed black ral 9005 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP44; the total weight is of 0.93 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 0.300 m length. The device features protection class III and can be ceiling-mounted, with a 127 mm diameter hole (in plasterboard). Compliant with the EN 60598-1 standard and its specific provisions.
FORMALIGHTING
RECESSED DOWNLIGHT
INDOOR LIGHTING
Round or Square mounting trim in cast aluminium with spring for installation mounting on a ceiling thickness of 1-25mm. Luminaire body in cast alluminum. Easy relamping tool-free via removable lamp front ring. Available in two different sizes. Adjustable version tiltable vertically 0-40° and rotatable horizontally 350°.
ILIGHT
CONTROL SYSTEM
CONTROL SYSTEM

BN-2-D is a DINrail mounted bridging module that allows 2 or more iLight iCANnetTM network segments to be connected together or arranged logically into floors or areas for ease of management. The bridge is also used to extend the network as a repeater where more than 500m of cabling is required or more than 100 network devices are used on one segment. BN-2-D also allows network messages to be filtered to ensure optimal performance in larger networks. BN-2-D allows multiple network segments to be connected together, enabling up to 65,000 devices to exist on a single system. It also improves reliability of larger systems by isolating and containing any network cabling faults when used correctly.
