MEYER

INGROUND UPLIGHT
OUTDOOR LIGHTING
8 659 016 059

Outdoor luminaire made of corrosion‑resistant die‑cast aluminum AlSi12, double polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass flush with frame, anti‑reflective coating from 1 side, dark screenprint, for loads up to max. 5000 kg (according to IEC / EN 60598‑2‑13), silicon gasket, cover frame and closure with 6 stainless steel screws.

DIMENSION : Ø 250 mm, width 216 mm.

Specification

Power
5W
Color Temperature
3000K
Light Source Type
LED
Lumen Output
343LM
Finishing
DIE-CAST ALUMINUM
IP Rating
IP67
Color Rendering
CRI>80
Driver
ON/OFF DRIVER
