SIMES

INGROUND UPLIGHT

OUTDOOR LIGHTING

S.4200W.09

Die cast EN AB-44300 aluminium (low copper content) housing with high corrosion resistance. Stone wash surface treatment prior to painting process. A4 grade Stainless Steel screws with 2,5-3% molybdenum content which increases the resistance against corrosion. Mechanical resistance IK 10. Maximum load capacity. This luminaire contains built-in LED modules. In case of damage or malfunction please contact the manufacturer to receive additional instructions on how to replace and relative spare parts to order. The LED modules cannot be handled in the luminaire by the end user. This product contains a light source of energy efficiency class: F. LED modules are engineered accordingly to the existing regulations of Lumen Maintenance (LM80) and Technical Memorandum (TM21), where uniformity and quality of the light is 70,000 hours referred to L80 B10 Ta 25 ° C (50,000 hours referable to L80 B10 Ta 40°C). Lifespan of the luminaire min. 50,000 hours at 40°C. Performance Ambient temperature Tq 25°C. Operating ambient temperature range is from -20°C to +50°C. Storage temperature range from -20°C to +60°C.

Specification

Power

6.5W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

38LM

Finishing

BLACK

IP Rating

IP67

Color Rendering

CRI 90

Driver

ON/OFF DRIVER

NEKO

ADJUSTABLE DOWNLIGHT

OUTDOOR LIGHTING

Square recessed downlight made of die-cast aluminium with black powder-coating finish (RAL 9005) and gold reflector; System Power 28W; measurements 134mm x 134mm x 159mm; ceiling cutout of...

PROLICHT

WALL LIGHT

INDOOR LIGHTING

The surface luminaire INVADER WALL from the familiy INVADER consists of aluminum. With 3 powder coated options 15625 colour combinations can be achieved. The ballast is integrated and allows for an operation with 220-240V (50/60Hz). INVADER WALL (# 320-0130) ist not dimmable (on/off). The spot with direct and indirect illumination corresponds to protection class SK1 at IP20.
