LINEALIGHT

Bollard with light output on all sides. Robust, trellised luminaire with square layout. Luminaire which provides surface illumination pathways, driveways and squares with light output on all sides. Luminaire made of aluminium profile, aluminium alloy, aluminium and stainless steel, IP65,IK07.

LED light source included. Head adjustable 350º on the vertical axis. Remote 24V electrical power unit sold separately. Unit comes with two 200-mm-long outgoing power cables and a kit for IP-rated connection. The power supply may be installed remotely (installation box not necessary) or housed behind the unit with the optional installation box. IP66,IK04.
