LINEALIGHT

PENDANT

INDOOR LIGHTING

64250W00

Single emission pendant luminaires for indoor application. The warm white LED light source with a diffused light distribution is composed of 288 topled LEDs. The device body is made of aluminium 6060 and features a embossed black ral 9005 finish, processed by means of powder coating; the diffuser is made of uv resistant polycarbonate. The ingress protection degree is IP40; the total weight is of 3 kg. The power supply driver is not provided and is to be ordered separately. The power supply cable is included and features a 5 m length. The device features protection class III and can be ceiling-mounted. Compliant with the EN 60598-1 standard and its specific provisions.

Specification

Power

45W

Color Temperature

3000K

Light Source Type

LED

Lumen Output

2348LM

Finishing

BLACK

IP Rating

IP40

Color Rendering

CRI 80

Driver

ON/OFF DRIVER

ENDO

ADJUSTABLE DOWNLIGHT

INDOOR LIGHTING

Recessed fixed downlight in matt white aluminium frame and mirror finish reflector. Cut-out 125mm. IP20

WE-EF

WALLWASHER

OUTDOOR LIGHTING

Marine-grade, all-aluminium construction. 5CE superior corrosion protection including PCS hardware. PMMA lens. Silicone rubber gaskets. 1.2 m of flexible PVC-free cable. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. DALI interface.

LINEALIGHT

SPOTLIGHT

OUTDOOR LIGHTING

Single emission projectors for indoor application. The super warm white LED light source with a flood light distribution is composed of 1 powerled LEDs with CCT of 2700 K and a CRI 90; the source luminous flux is 358 lm, with a 119.3 lm/W nominal luminous efficacy.

The device body is made of aluminium and features a dark brown finish, processed by means of powder coating. The ingress protection degree is IP40; the total weight is of 0.08 kg. The power supply driver is not provided and is to be o
