LED LINEAR

Square recessed motorized luminaire with retractable light head. Mounting trim and light head are made of cast aluminium, recessed light housing made of painted metal. Moto-Palla In&Out is available in 3 different light head diameters: 66mm, 100mm and 130mm. The luminaire includes brackets for trim installation on ceiling thickness max. 25 mm or trimless installation on ceiling thickness max. 30 mm. Two remote controlled DC motors drive the movements of the fixtures. The fixtures are rotatable horizontally 350° and, tiltable vertically in two directions (0°-10° In, 0°-90° Out). The movements of the fixture, as well as the intensity and the colour tuning of the light, are controlled via CASAMBI™ application.

Round recessed trimless downlight (Easy Installation) made of die-cast aluminium with white powder-coating finish (RAL 9016) and white reflector; System 15W; measurement Ø73mm x 90mm; ceiling cutout of Ø78mm with a trimless mounting; ceiling thickness 1-20mm; rotation 355° and pivot max. 30°; CCT 3000K with a System luminous flux of 1200lm;high color rendering at an index of CRI90; after a lifetime of 50000h L90B10 min. 90% of the luminous flux with energy efficient BRIDGELUX LED Chips; 5 years

Luminaire made of aluminium profile, aluminium alloy, aluminium and stainless steel BEGA Unidure® coating technology Colour graphite or silver Safety glass with optical structure Silicone gasket Reflector made of pure anodised aluminium Luminaire with mounting plate for bolting onto a foundation or an anchorage unit Mounting plate with two pitch circles: ø 100mm, 3 elongated holes 9mm wide ø 132mm, 3 elongated holes 9mm wide Luminaire can be aligned on the mounting plate around 360°

Recessed or Surface mount magnetic track system containing linear light, spot light, wall washer and pendant light module to create your imagination of illumination purposes in a wonderful visual experience. Low voltage DC48V plus double insurance installation system magnetic + click make it work safely. Reflector come with Silver, Chrome Black and White and honeycomb accessory available upon request.
