LIGHTFORMS

The recessed spot OIKO from the familiy OIKO consists of aluminum-die-cast. The article can be powder coated in 25 colours. Stated photometric values correspond to operation by 700 mA; a suitable ballast needs to be sourced separately and is not scope of delivery. Dimming (# 22345) depends on the used ballast and may vary. The spot with direct illumination corresponds to protection class SK3 at IP20. ZERO LIGHT LEAKAGE technology guarantees trouble-free use in acoustic ceilings.

Round ceiling recessed downlight made from die-cast aluminium adjustable surface. Black Matt; powder coated, matt texture RAL 9005; installation without tools using blade springs. Suitable for ceiling thickness of min. 6 mm, recessed depth 90 mm; with COB (Chip on Board) technology for maximum efficiency. Bining initial MacAdam ≤ 2 SDCM; CRI ≥ 90; beam angle 34°; 355° rotatable and 35° tiltable; degree of protection IP20.

The luminaire housing made of die‑cast aluminum AlSi12, polyester powder coated by high‑quality and UV‑stabilized coating process. All exterior parts are stainless steel, tempered safety glass, anti‑reflective coating from 1 side, dark screenprint, silicon gasket, closure with 4 stainless steel screws, mounting bracket powder coated aluminum. The ingress protection degree is IP67, IK08. DIMENSIONS : (L×H×W): 280 × 162 × 280 mm.

Track Adjustable Spotlight luminaire body made of aluminium housing with white powder coated finish. Black finish and honeycomb accessory available upon request.
