Recessed luminaire with LED light source. Power supply not included. Installation frame not necessary.

1 side - Supplied with specific 4 m cylindrical, straight aluminium pole: APD140114-DE1

Dot designed to be integrated in new or retrofitted handrails. Suitable for outdoor: IP66, IK10, and anti-vandalism. Flat and curved types. 3 beam angles: 60o, 120o and 90o (asymmetric). Luminous efficiency: 100 lm/W. 316 stainless steel unibody dot. Polycarbonate lens. Accessories: Installation tool and M16 Drill jig equipment.

Housing made of corrosion‑resistant die‑cast aluminum AlSi12, polyester powder coated by high‑quality and UV‑stabilized coating process, Colour: black ral 7021, all exterior parts are stainless steel, tempered safety glass, anti‑reflective coating from 1 side, dark screenprint, silicon gasket, closure with 4 stainless steel screws, 2 drilled holes Ø 7 mm, spacing 30 ‑ 40 mm, 1 centre hole Ø 21 mm, tilt range: 180°, cable gland: M20, connecting terminal: 3 pole, precise PMMA optics, integral driver (AC/DC), CRI > 80, max 2 SDCM, service life L90/B10 > 50.000 h, Beam angle (fwhm): 6°, luminous flux: 3086 lm, wattage: 37 W, delivered lumens 83 lm/W, protection type IP65, protection class I, impact resistance IK08, windage area 0,02 m², dimensions (L×H×W): 152 × 120 × 152 mm, weight 2.4 kg. The modular luminaire design makes the replacement of components possible. The product meets the demands of the applicable EU guidelines and product safety regulations and bears the CE mark. Customized solutions and modifications are possible: Special ral, db or ncs colours as polyester powder coat, luminaires in 2700 K and other colour temperatures and versions for high ambient temperature.
