PHOS

RECESSED DOWNLIGHT
INDOOR LIGHTING
NA-EE-TF_2700K-30°

The Nano Eclipse Trimless is a recessed downlight with a trimless plaster in frame and features a beautifully sculpted anti-glare baffle. Unique, elegant small aperture, 360° rotation. Easily interchangeable optics. Flawless finishes available on all components. Part of a wide family range of fully modular luminaires.

Specification

Power
1W
Color Temperature
2700K
Light Source Type
LED
Lumen Output
115LM
Finishing
WHITE
IP Rating
IP20
Color Rendering
CRI 92
Driver
ON/OFF DRIVER

See more
